Siemens Sonoline G40 CH5-2 Transducer
5-2 MHz Curved Transducer for OBGYN, Abdomen, Renal, Urology, Fetal Echo and Emergency Medicine
Bandwidth:
- 5-2 MHz, Curved Array Transducer
- B-Mode Frequencies: 2.5 MHz, 3.7 MHz, 5.0 MHz
- THI Frequencies 2.2 MHz, 1.8 MHz
- Color Doppler Frequencies 2.0 MHz, 2.7 MHz
- PW Doppler Frequencies 2.0 MHz, 2.7 MHz
- Aperture 14 mm x 61 mm
- Number of Elements 128
- Array Length 61.1 mm
- FOV (maximum) 68º
- Display Depth (maximum) 28 cm
- ROC 61.2 mm
Features
- Wide bandwidth curved array transducer
- User selectable MultiHertz™ multiple frequency imaging
- Ergonomically designed form factor
- Lightweight transducer with flexible transducer cable
- 2D, THI, Color Doppler, Power Doppler, PW Doppler and M-Mode
Applications:
- OB/GYN
- Abdomen
- Renal
- Urology
- Fetal Echo
- Emergency medicine
Compatible Systems:
- SONOLINE G40™ ultrasound system
- Acuson X150™ ultrasound system
Accessories:
- CH4-1 Needle Guide Kit, PN 7472314
