Siemens Sonoline G40 VF10-5 Transducer
10-5 MHz Linear Transducer for Breast, Thyroid, Testicle, MSK, Ortho, Vascular, Venous, Emergency Medicine
Bandwidth
- 10-5 MHz, Linear Array Transducer
- 2D Mode Frequencies 6.2 MHz, 8.0 MHz, 10.0 MHz
- THI Frequencies 4.0 MHz, 4.7 MHz
- Color Doppler Frequencies 5.3 MHz, 6.7 MHz
- PW Doppler Frequencies 5.3 MHz, 6.7 MHz
- 2D Doppler Steering Angle +/- 12ºnormal +/- 15º wide
- Color Doppler Steering Angle +/- 12º
- PW Doppler Steering Angle +/- 12º
- Aperture 5 mm x 39 mm
- Number of Elements 128
- Array Length 38.7 mm
- FOV (maximum) 78 mm
- Display Depth (maximum) 10 cm
Features
- Wide bandwidth Virtual Format transducer with 2D beam steering and trapezoid imaging capabilities
- User selectable MultiHertz imaging
- Ergonomically designed form factor
- Lightweight transducer with flexible transducer cable
- 2D, THI, Color Doppler, Power Doppler, PW Doppler and M-Mode
Applications
- Breast
- Thyroid
- Testicle
- MSK
- Ortho
- Vascular
- Venous
- Emergency medicine
Accessories
- Biopsy Guide SG-3 Needle Guide Kit, PN 7296481
Compatible Systems:
- SONOLINE G40™ ultrasound system
- Acuson X150™ ultrasound system
- Acuson X300™ ultrasound system
